TC ROUTER 3002T-4G - Router | 2702528
- LTE 4G industrial router, emergency switching to 3G UMTS/HSPA+ and 2G GPRS/EDGE, 2 Ethernet interfaces, firewall, NAT, IPsec and OpenVPN support, 2x SMA-F antenna socket, SMS and e-mail sending, 2 digital inputs , 1 digital output
Industrial routers for remote management and cybersecurity
Our robust industrial routers connect different networks via cable (LAN and NAT) or cellular technology (2G/3G/4G/5G) for remote management and securing local networks. Many of our products feature built-in VPN and firewall functions. To ensure full protection, mGuard routers protect against cyber attacks and malware.
Ethernet |
Type of connection: |
|
Transmission speed: |
| 10/100 Mb/s (Auto-negotiation) |
|
Transmission range: |
| 100 m (Twisted Pair, shielded) |
|
Number of channels: |
|
Supported protocols: |
| TCP/IP, UDP/IP, FTP, HTTP(S) |
|
Auxiliary protocols: |
| ARP, DHCP, PING (ICMP), SNMP V1/V2, SMTP(S), NTP, SSL/TLS, STARTTLS |
|
Wireless transmission: |
Interface description: |
| GSM / GPRS / EDGE / UMTS / HSPA+ / LTE |
|
Frequency range: |
| 2600 MHz (LTE B38) |
| 2500 MHz (LTE B41) |
| 2300 MHz (LTE B40) |
| 2100 MHz (LTE B1) |
| 1800 MHz (LTE B3) |
| 2600 MHz (LTE B7) |
| 900 MHz (LTE B8) |
| 800 MHz (LTE B20) |
| 700 MHz (LTE B28A) |
| 2100 MHz (UMTS/HSPA B1) |
| 900 MHz (UMTS/HSPA B8) |
| 900 MHz (2 W (EGSM)) |
| 1800 MHz (1 W (EGSM)) |
|
Transmission speed: |
| ≤ 150 Mbit/s (LTE, DL) |
| ≤ 50 Mbit/s (LTE, UL) |
|
SIM slot: |
|
Product properties: |
Application: |
|
MTTF: |
| 383 Years (Standard SN 29500, temperature 25°C, duty cycle 21%) |
| 184 Years (Standard SN 29500, temperature 40°C, duty cycle 34.25%) |
| 78 Years (Standard SN 29500, temperature 40°C, duty cycle 100%) |
|
Electrical parameters: |
Galvanic isolation: |
| VCC // LTE // Ethernet // PE |
|
Network type: |
|
Maximum power loss under rated conditions: |
|
Power supply voltage range: |
|
Typical current consumption: |
| < 200 mA (24 V DC) |
| 65 mA (With active power-saving mode) |
|
Maximum current consumption: |
|
Installation |
Mounting method |
|
Dimensions |
 |
| Width: 45 mm |
| Height: 130 mm |
| Depth: 127 mm |
|
Benefits
- High reliability due to LTE CAT4 cellular network support.
- Remote management via web interface and SNMP.
- Resistant to a wide range of environmental conditions from -40°C to 70°C.
- Integrated support for various TCP/IP communication protocols and wireless data transmission technologies.
- Robust design meeting CE standards and resistance to electromagnetic interference.
