  • The UR75-L04EU-G-W industrial GSM/LTE router is a powerful and reliable device designed for a wide range of industrial applications. It has built-in GSM/LTE modules for easy and fast network connectivity
Size
uniwersalny
1 617,67 zł
net / szt.
Lowest price in 30 days before discount: / szt.
Regular price: / szt.
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Industrial Router UR75-L04EU-G-W

UR75 4G
Industrial Cellular Router

Durable and Reliable

  • Ultra-fast connectivity and high reliability
  • Versatile interfaces for various applications
  • Industrial-grade design for harsh environments
  • Remote management
Industrial Router UR75-L04EU-G-W

Ultra-Fast Connectivity

  • Superior 5G Network
    5G Sub-6GHz enables wider signal coverage with an outstanding download speed of up to 4.67 Gbps (Models UR75-504AE-W2 / UR75-504AE-P-W2)
  • High-Performance Wi-Fi
    Wi-Fi 6 allows simultaneous dual-band 2.4G and 5G connections with a download speed of up to 1.8 Gbps.
Industrial Router UR75-L04EU-G-W

Advanced OpenCPU System

The UR75 is equipped with an enhanced ARM Cortex-A55 quad-core processor and larger memory for faster data transmission.

By adopting the OpenCPU system, the UR75 offers a more streamlined yet efficient structure with the following advantages:

  • Lower power consumption
  • Reduced investment costs
  • Enhanced flexibility and performance
Industrial Router UR75-L04EU-G-W

High Performance

  • Fast Backup Creation
    Automated failover/backup between Ethernet, cellular network (dual SIM), and Wi-Fi.
  • Built-in Watchdog
    Integrated hardware watchdog for automatic recovery after failures.
  • Security Protection
    Equipped with multiple security measures, such as ACL, DMZ, SYN-Flood protection, and data filtering to ensure network security.
Industrial Router UR75-L04EU-G-W

Versatile Interfaces for Multiple Applications

The UR75 supports serial ports (RS232/RS485), I/O (input/output), and GPS, allowing for scalable M2M applications. It also features a USB 3.0 (Type-C) port for power supply, network power, and debugging.

Industrial Router UR75-L04EU-G-W

Industrial-Grade Design for Harsh Environments

With a wide operating temperature range from -30°C to 60°C and a metal housing rated IP30, the UR75 remains efficient even in extreme conditions.

Industrial Router UR75-L04EU-G-W

MilesightVPN

The UR75 supports connection and management through MilesightVPN.

  • Easy connection via authentication code
  • Connection status overview
  • Remote and secure access to external devices
Industrial Router UR75-L04EU-G-W

DeviceHub

Milesight DeviceHub provides a high-performance, easy-to-maintain solution for effortless deployment of Milesight industrial cellular routers across multiple locations, reducing complexity and increasing productivity.

  • Centralized management
  • Device status monitoring
  • Remote and bulk configuration
pixel
Brand
Milesight
Producer code
6974225032587
Series
Ultra Series
Hardware System
CPU
Quad-core ARM Cortex-A55，2 GHz
Memory
1 GB LDDR4x RAM and 1 GB NAND Flash
Extendable Storage
1 × M.2 NVMe SSD Interface
Cellular Interface
Network
5G NR SA & NSA/4G LTE/WCDMA
Frequency
WCDMA: B1/B5/B8
LTE TDD: B38/B40/B41/B42/B43
LTE FDD: B1/B3/B5/B7/B8/B20/B28/B32
5G Sub-6: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78
Antenna
4 × 50 Ω SMA Connectors (Center PIN: SMA Female)
SIM Slot
2（Mini SIM-2FF）
Ethernet Interface
Numbers
5 × 10/100/1000 Mbps
Property
1 × WAN +4 × LAN
Mode
Full or half duplex (Auto-Sensing)
PoE
4 × 802.3 af/at PoE PSE on LAN Ports (Optional)
Wi-Fi Interface (Optional)
Antenna*
4 × 50 Ω SMA Connectors (Center PIN: RP-SMA Female)
Standards
IEEE 802.11b/g/n/ax 2 x 2 MIMO, 2.4 GHz
IEEE 802.11a/n/ac/ax 2 x 2 MIMO, 5 GHz
Max Bit Rate
2.4 GHz: 600 Mbps, 5 GHz: 1200 Mbps
Modes
AP Mode
Security
WEP/WPA/WPA2 authentication, WEP/TKIP/AES encryption
GNSS
Antenna**
1 × 50 Ω SMA Connector (Center PIN: SMA Female)
Technology
GPS/GLONASS/Beidou/Galileo/QZSS
Protocol
NMEA 0183
Serial Interface
Numbers*
1 × RS232 + 1 × RS485
Connector
3.5 mm Terminal Block
Baud Rate
300bps to 230400bps
DI/DO
Numbers**
1 × DI (Dry Contact) + 1 × DO (Wet Contact)， Galvanic Isolation
Connector*
3.5 mm Terminal Block
Maximum V/A
0.3A@30VDC (DO)
Others
USB
1 × USB 3.0 (Type-C) for Power Supply, Network Supply and Debug
Reset Button
1 × RESET
LED Indicators
1 × SYSTEM，1 × SIM1，1 × SIM2
Built-in
Watchdog, Timer
Software
Network Protocols
IPv4/IPv6, TCP, UDP, DHCP, HTTP, HTTPS, ARP, NTP, DNS, ARP, SSH, etc.
VPN
IPsec, OpenVPN
Security
Access Control, DMZ, Port Forwarding, SYN-Flood Protection, Filtering (IP & MAC & Domain)
Management
Web, DeviceHub, MilesightVPN
Multilevel Authority
Multiple Levels of User Authority
Reliability
WAN Failover, Dual SIM Backup
Serial Port
Transparent (TCP Client/Server, UDP), Modbus Master, Modbus Gateway (Modbus RTU to Modbus TCP)
Power Supply and Consumption
Power Connector
2-pin 3.5 mm Terminal Block
Power Input
1. 9-48 VDC, with Surge-Protection and Reverse Polarity Protection
Power Consumption (In Non-PoE mode)
Without Wi-Fi: Typical 2.8 W, Max 5.5 W
With Wi-Fi: Typical 7 W, Max 13.7 W
Physical Characteristics
Ingress Protection
IP30
Housing
Metal
Dimension
135 x 115 x 36.4 mm (5.31 x 4.53 x 1.43 in)
Installation
Desktop, Wall or DIN Rail Mounting
Environmental
Operating Temperature
-30°C to +60°C (-22℉ to +140℉)
Storage Temperature
-40°C to +85°C (-40℉ to +185℉)
Ethernet Isolation
1.5 kV RMS
Relative Humidity
0% to 95% (non-condensing) at 25°C/77℉
